Features
100% Brand new
Module Properties: non-isolated buck.
Light compact, convenient to use and transport.
Rectification: synchronous rectification.
All epoxy sealed containers with Waterproof Housing.
Operating Temperature: Industrial (-40℃ to +85℃) (ambient temperature exceeds 40 degrees, lower power use, or to enhance heat dissipation).
With overload/over-current/overheat/low voltage protection, stable performance.
Short circuit protection: sustainable, self-recovery.
Input Reverse Polarity Protection: No, if necessary, enter the series diode.
Specifications
Input voltage: 12V
Output voltage: 5V
Output current(MAX): 3A,total.
Rated power: 15W
Conversion efficiency: up to 96%
Soft-start time: 500mS
Output ripple: 50mV (MAX) 20M-bandwidth
Dynamic response speed: 5% 200uS
Usb cable length:30cm.from regalutor to usb connector.
Size: 46x27x14mm
Package included
DC12v to 5v 15W Socket x 1
