20Pin Universal Aftermarket Car Head Unit DVD Stereo Radio Wiring Harness Cable Plug

SKU: #2326
Old price: 3.89 (EUR)
1.68 (EUR)
PRICE BREAKS - The more you buy, the more you save
Quantity1+11+21+31+41+
Price1.68 (EUR)1.60 (EUR)1.55 (EUR)1.52 (EUR)0.55 (EUR)
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options


Features:
Many aftermarket car head unit use this wiring harness plug cable,but each pin's electrical
defined feature is different,you can buy this harness and adjust each pin's possition by yourself
according to your car head unit old original wire diagram.

20Pins electrical features defined as follow:
#1 GND-
#2 BAT+
#3 Rear Right Speaker-
#4 Rear Right Speaker+
#5 Front Right Speaker-
#6 Front Right Speaker+
#7 Rear Left Speaker+
#8 Rear Left Speaker-
#9 Front Left Speaker+
#10 Front Left Speaker-
#11 Brake
#12 Acc.+
#13 Amp. Control
#14 Backup(Reverse)
#15 SWC+(Steering Wheel Control)
#16 Ant.Control
#17 SWC-
#18 N/A
#19 illum. Light Control
#20 N/A
